REED R5002 Insulation Tester - 5kV

• Wide range measurements from 500V to 5000V and up to 60GΩ
• Sources up to 1.2mA current during tests to offset capacitance load
• Polarization index measurement (PI)
• Dielectric absorption ratio measurements (DAR)
• Time set measurement function
• Auto-discharge function and voltage output warning function
• Live circuit warning symbols plus audible warning
• Live circuit detection prevents insulation test if >30V is detected
• Max/Min, Peak, Relative value and Data Hold functions
• 6000-count digital display with bargraph and backlight
• Meets IEC61010-1 Cat. IV 600V safety standards
• Power Supply: 8 x 1.5V "C" R14 batteries
• NIST Traceable Certification Available
• Dimensions: 7.8 x 5.8 x 3.4"
• Weight: 1.5 kg (3 lb)
• Includes test leads, batteries and carrying case.

Insulation Resistance Tests:

• Test Voltages: 500V, 1000V, 2500V, 5000V DC
• Measurement Range: 0 to 60.0GΩ
• Accuracy: ±5% rdg. +3 dgt.
• Open Circut Voltage: +20%, -0%
• Rated Current: 1 to 1.2mA
• Short Circuit Current: Approx. 1.3 mA

Resistance Tests:

• Measurement Range: 0.1 to 6000Ω
• Accuracy: ±1.5% rdg. +10 dgt.
• Continuity Test: Buzzer sounds at <50Ω
• Short Circuit Current: ≥200mA
• Open Circuit Test Voltage: ≥4.5V

Voltage Tests:

• Measurement Range: 0.5 to 600.0V AC/DC
• Accuracy: ±1.5% rdg. +5 dgt.

REED R5002 5kV Insulation Tester RD-R5002 $764.10

*  *  *  *  *  *  *

R5002 5kV Insulation Tester w/ NIST RD-R5002-NIST $903.60

>> R5002 DataSheet

>> R5002 Manual (PDF)
