Scale Master II

• Dramatically Cut Take-Off Time
• Speed Estimates
• Improve Profit
• Reduce Errors
• Improve Crew Productivity

Unlike "old fashioned" scalers or rulers, the Scale Master II is a digital and multi-functional device. Yet, it's highly accurate, portable, and easy-to-use! Our newest model contains 91 architectural, engineering, map & metric blueprint scales, simpler & enhanced features, and even PC interface capability-- to help you estimate like a pro! It's an "all-in-one" take-off tool.

• User Accuracy
  Based on how accurately you roll (or start and stop). Error factor approx. 2-4%. Highly accurate for estimating.
• A Total of 91 Built-In Scales
  With 50 imperial (feet-inch) and 41 metric, there's a scale for almost any plan.
• Small, Lightweight and Totally Portable (Fits in Your Pocket)
  Even bring it with you to the field!
• Perform Instant Linear, Rectangular Area & Volume Take-Offs
  Use it like a pen--just roll & measure! Align the white line on the red wheel to the starting point, and roll!
• Rolls-in Distances in Either Direction
  Accepts dimensions as fast as you can accurately roll them in either direction and with either hand. Measures regular & irregular linear distances, or odd shapes.
• Easy-to-Read Display
  Reads your measurement in feet/inches or metric.
• Multiple Dimensional Units for Maximum Versatility
  Select your favorite measurement units: decimal feet, feet-inches, decimal inches, yards, millimeters, meters, kilometers--including square and cubic formats of each.
• Convert Between Scales & Dimensions
  If dealing with more than one scale or dimension.
• Custom Scale
  Eight (8) user-set custom scales. Perfect for scaling faxed or out-of-scale plans. Calibrates to any plan and then stores that scale for future use.
• Calculate Rectangular Areas/Volumes (LxWxH)
  Just roll & enter length of room, then width & instantly calculate square footage. Or put in Memory to accumulate total square footage.
• Subtract, Constant & Counter
  Lets you subtract if you roll too far. And lets you count items (e.g., studs, outlets, etc.) & accumulate in memory. Constant (+K) key allows you add or subtract a constant value to the distance measured. Great for "drops" and add-ons.
• Durable and Portable for Field or Office Use
• Optional PC Interface Kit - (for Serial or USB)

Scale Master II Specifications:

• Size:
  7.2 x 1.6 x 0.6" (182 x 41 x 15 mm)
• Product Weight (product only with battery):
  1.9 oz. (54 g)
• Wheel Resolution:
  0.025" (0.635 mm)
• Wheel Composition:
  Celcon Polymer
• Power:
  Two 3-volt lithium (CR-2430) batteries (included)
• Bat. Life:
  400+ hours usage
• Auto Shut-off:
  5 min.
• Keypad:
  12 keys; soft-touch silicone rubber
• User's Guide:
  44 pp.; 5.0 x 2.5" (127 x 64 mm)
• Warranty:
  1-Year Limited Warranty
• Case:
  High-impact ABS hinged case
• Operating Temperature:
  32-130 deg. F (0-55 deg. C)
• Display Type:
  LCD segment; 7 digit main display, 3 digit count, 5 digit scale display, with annunciator-legends
• Display Dimensions:
  0.76 x 2.5" (19 x 64 mm)
• Accuracy:
  2-4%, based on user's start & stop accuracy; 10 digit internal accuracy
